ڈھلوان سطح ⇐فرض کیجئے کہ کسی وزن کو زمین سے کسی بلندی تک اٹھانا ہے۔ کیا اسے سیدھا اوپر اٹھانا آسان ہوگا ۔ یا ڈھلوان راستے سے ڈھلوان راستے سے کم قوت ( زور) لگتی ہے۔ یہ بات کمانی تراز و سے معلوم کی جاسکتی ہے۔ (کمانی تر از و براه راست قوت مانپتا ہے ) کسی وزن کو کمانی تراز سےلٹکاکر سیدھا اوپر کھینچئےاور اس پر قوت پڑھیے۔ پھر اسی وزن کو کسی ڈھلوان سطح پررکھ کر اوپر کھینچئے۔ اب کمانی ترازو کم زور پاتی ہے۔
Sloping surface Suppose a weight is to be lifted from the ground to a certain height. Will it be easier to lift it straight up? Or will it take less force (force) from a sloping path than from a sloping path? This can be found out using a balance. (A balance measures force in a straight line) Hang a weight from a balance and pull it straight up and read the force on it. Then place the same weight on an inclined surface and pull it up. Now the balance experiences less force.
مشین
اس کی وجہ یہ ہے کہ ڈھلوان سطح کے راستے اسی مزاحمت (وزن ) کو آہستہ آہستہ سر کیا جاتا ہے، جب کہ سیدھااٹھانےمیں پورے وزن کا مقابلہ کیا جاتا ہے۔ ڈھلوان سطح کے استعمال سے تقدیم زمانے میں مصریوں نے ہزاروں ٹن بھاری پتھروں سے بلند مخروطی مینار تعمیر کیے۔ آج بھی ڈھلوان سطح عام استعمال کی مشین ہے مثلاً آپ جانتے ہیں کہ مکان کی چھت بنانے کیلئے پہلے چھت تک تختوں کا ڈھلوان راستہ تیار کیا جاتا ہے۔ اس راستے سے چھت کی تعمیر کیلئے مزدور بھاری سامان اٹھاتے ہیں سیدھا اوپر اٹھانے کے مقابلے میں یہ راستہ آسان ہوتا ہے۔
Machine
The reason for this is that the same resistance (weight) is overcome gradually through the inclined surface, while in the straight lift the entire weight is resisted. In ancient times, the Egyptians built tall conical towers with thousands of tons of heavy stones using the inclined surface. Even today, the inclined surface is a commonly used machine. For example, you know that to build the roof of a house, a sloping path of planks is first prepared up to the roof. This path is used by workers to lift heavy materials for the construction of the roof. This path is easier than lifting straight up.
لکڑی
شکل میں دکھائے ہوئے طریقے سے کاغذ کی ایک ڈھلوان سطح کاٹ کر پینسل پر لپیٹئے۔ اب ڈھلوان سطح سکریو کی شکل اختیار کر لیتی ہے دو چکروں کا درمیانی فاصلہ پچ” کہلاتا ہے۔ سکر یو لپٹی ہوئی ڈھلوان سطح ہے۔ سکریوز پر زور کے پورے ایک چکر سے مزاحمت صرف ایک پچ کے برابر ہوتی ہے لہذا جب سکر یو کو ایک چکر لکڑی کے اندر کیا جاتا ہے تو وہ لکڑی کے اندر سکریو کی بیچ کے برابر ہی فاصلہ طے کرتا ہے۔
Wood
Cut a sloping surface of paper as shown in the figure and roll it around a pencil. Now the sloping surface takes the shape of a screw. The distance between two turns is called the “pitch”. A screw is a rolled sloping surface. The resistance to the force exerted on the screw by one complete turn is equal to only one pitch, so when the screw is turned once inside the wood, it travels a distance inside the wood equal to the distance between the screws.
مشینوں سے کام آسان کرنے کے طریقے
جب اصول کار کے مطابق ان پٹ, آؤٹ پٹ ہے تو پھر مشین سے کام لینے میں ہمیں کیا فائدہ ہے مشینیں ہمارا کام تین طریقوں سے آسان کر سکتی ہیں۔
زور کی سمت بدل کر
زور کو پڑھا کر
کام کی رفتار یا زور کی پہنچ بڑھا کر
Ways to make work easier with machines
When according to the principle of work there is input, output, then what is the benefit to us in working with machines?
Machines can make our work easier in three ways.
- By changing the direction of force
- By reducing the force
- By increasing the speed of work or the reach of force
مشین زور کی سمت بدل سکتی ہے
مشین سے زور کی سمت بدلنے کی مثال ہم پلی سے سمجھ سکتے ہیں۔ کنویں سے پانی نکالنے کیلئے پلی کا استعمال کیا جاتا ہے۔ پلی کے ذریعے زور کی سمت کو نیچے کی جانب کیا گیا ہے۔ اس طرح سے پلی کا استعمال کر کے مزاحمت کو کم کیا جاتا ہے۔
Machine can change the direction of force
We can understand the example of changing the direction of force from a machine with a pulley. A pulley is used to extract water from a well. The direction of force is directed downwards through the pulley. In this way, resistance is reduced by using a pulley.
مشین زور کو بڑھا سکتی ہے
کیا آپ سخت اخروٹ کو ہاتھوں سے توڑ سکتے ہیں ؟ سروتے سے کیوں آسانی سے ٹوٹ جاتا ہے؟ اگر آپ سمجھتے ہیں کہ سرو تا فولاد کا بنا ہوا ہے اس لیے با آسانی ٹوٹ جاتا ہے تو اخروٹ کے دونوں طرف دو سکے رکھ کر پھر انگلیوں سے دبا کر توڑنے کی کوشش کیجیئےنہیں وجہ سروتےکی سختی ہے۔ اس کا جواب صرف یہ ہے ہو سکتا ہے کہ سروتاآپ کے زور کو اخروٹ پر بڑھا کر لگاتا ہے۔ اس طرح ایک بھاری پتھر کو ہاتھ سے نہیں اٹھایا جا سکتا لیکن ایک سلاخ کی مدد سے ہاتھوں کے اتنے ہی زور سے با آسانی اٹھا یا یا دھکیلا جا سکتا ہے۔ یعنی سلاخ ایک مشین ہے جو زور کو بڑھا کر مزاحمت پر لگاتی ہے۔
ان پٹ آؤٹ پٹ یعنی
زور زور کے عمل کا فاصلہ = مزاحمت و مزاحمت کے عمل کا فاصلہ
Machine can increase the force
Can you crack a hard walnut with your hands? Why does a screwdriver break easily? If you think that a screwdriver is made of steel and therefore breaks easily, then try to crack it by placing two coins on both sides of the walnut and then pressing it with your fingers. No, the reason is the hardness of the screwdriver. The answer is simply that the screwdriver increases your force on the walnut. In this way, a heavy stone cannot be lifted by hand, but with the help of a rod, it can be easily lifted or pushed with the same force of the hands. That is, the rod is a machine that increases the force and applies it to resistance.
Input Output means
Distance of force = distance of resistance and resistance
بودی مزاحمت
اگر مشین کے ذریعے کسی بودی مزاحمت کو کم زور سے سر کیا جاتا ہے تو ساتھ ہی مزاحمت کی نسبت زور کو زیادہ فاصلے تک عمل کرنا ہوگا تاکہ( ان پٹ =آؤٹ پٹ ہو ) چنانچہ مشین کا کردار یہ ہے کہ ہم تھوڑے زور کو زیادہ دورتک لگا کر اس سے بڑی مزاحمت کو کم فاصلے تک سر کر سکتے ہیں۔ البتہ صرف ہونے والی توانائی یا کام کم نہیں ہوتا۔ اکثر ہی زور بڑھانے کی ضرورت پڑتی ہے اس لیے مزاحمت اور زور کا تناسب خاص اہمیت رکھتا ہے اور اسے کسی مشین کا میکانی فائدہ کہتے ہیں۔
Physical Resistance
If a physical resistance is overcome by a machine with less force, then at the same time the force has to be applied to a greater distance than the resistance so that input = output. Therefore, the role of the machine is that we can overcome a greater resistance to a shorter distance by applying a small force to a greater distance. However, the energy or work consumed does not decrease. Often there is a need to increase the force, so the ratio of resistance to force is of particular importance and is called the mechanical advantage of a machine.
پرزے
کیا ہر مشین کے ذریعے زور بڑھ کر لگتا ہے؟ نہیں، کسی گھڑی ساز کو چمٹی سے گھڑی کے نازک پرزوں سے کام کرتے دیکھئے۔ اسے اپنے زور کو بڑھانے کی ضرورت نہیں ہے بلکہ چمٹی سے وہ اپنی ضروریات سے زیادہ زور کو کم کر کے لگاتا ہے۔ لہذا مشین زور کو زیادہ یا کم کر سکتی ہے ۔
Parts
Does every machine apply force increments? No, watch a watchmaker working with tweezers on the delicate parts of a watch. He does not need to increase his force, but with the tweezers he applies more force than he needs. Therefore, the machine can increase or decrease the force.
مشین کام کی رفتار بڑھا سکتی ہے
پیروں سے پہیہ گھمایا جاتا ہے جس سے دوسرا پہیہ گھومتا ہے۔ پہیہ کے صرف ایک چکر سے دوسرا پہیہ کئی چکر پر لگائے گا۔ دوسرا پہیہ سائیکل کے پچھلے پہیےکے ساتھ منسلک ہے اور اس طرح اس کی حرکت تیز ہوتی ہے۔
The machine can increase the speed of work
The wheel is turned by the feet, which causes the second wheel to turn. With just one turn of the wheel, the second wheel will rotate several times. The second wheel is connected to the rear wheel of the bicycle and thus its movement is accelerated.
لیور
لیورر عموما سلاح نما (لیکن یہ ضروری نہیں ہے ) سخت جسم ہوتا ہے۔ جو چیزوں کو حرکت دینے میں مدد دیتا ہے۔
Lever
A lever is a rigid body, usually in the form of a lever (but not necessarily a lever), that helps to move things.
ہم أمید کرتے ہیں آپ کو “ڈھلوان سطح“ کے بارے میں مکمل آگاہی مل گئی ہوگی۔۔۔
